Authenticating applications using OpenID Connect on K8s using Sidecar - Part 2

Peter Mendis

Jul 06, 2020 - 4 Min read

Welcome to Part-2 of “Authenticating web applications using OpenID Connect without having to change to app code”

I am going to follow this article from openshift to setup and configure OpenID-Client Client

Here is the summary of things that you need to perform and you could follow the above article.

You have to create the following using the admin console of Keycloak server

Create ClientID “gatekeeper”
Create Protocol Mapper - “audience”
Add Users and Groups

Note: You may use “master” realm or create your own realm say “local”

For this example, I am going to stick with default “master” realm.

I did not use Ingress but instead leveraged kubectl port-forward feature to expose both keycloak server url as well as the keycloak gateway sidecar.

For this example, I used my gatsby application container as sample web application. This is simple static documentation application hosted in Nginx Server. The docker image can be found under the docker hub https://hub.docker.com/repository/docker/livecontainer/nginx-gatsby-sample

For more information about this image please refer my git repo here

Here are the resource definition files for deploying applications, sidecar/gatekeeper in kubernetes cluster.

deployment.yaml

---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-gatsby
  namespace: ns-keycloak
spec:
  replicas: 1
  selector:
    matchLabels:
      app: nginx-gatsby
  template:
    metadata:
      labels:
        app: nginx-gatsby
    spec:
      containers:
        - name: nginx-gatsby
          image: livecontainer/nginx-gatsby-sample:latest
          resources:
            limits:
              cpu: "1"
              memory: 512Mi
            requests:
              cpu: "0.5"

        - name: gatekeeper
          image: carlosedp/keycloak-gatekeeper:latest
          resources:
            limits:
              cpu: "1"
              memory: 512Mi
            requests:
              cpu: "0.5"
          args:
            - --config=/etc/keycloak-gatekeeper.conf
          ports:
            - containerPort: 3000
              name: service
          volumeMounts:
            - name: gatekeeper-config
              mountPath: /etc/keycloak-gatekeeper.conf
              subPath: keycloak-gatekeeper.conf
            - name: gatekeeper-files
              mountPath: /html
      volumes:
        - name: gatekeeper-config
          configMap:
            name: gatekeeper-config
        - name: gatekeeper-files
          configMap:
            name: gatekeeper-files

configmap.yaml

---
apiVersion: v1
kind: ConfigMap
metadata:
  name: gatekeeper-config
  namespace: ns-keycloak

data:
  keycloak-gatekeeper.conf: |+
    # is the url for retrieve the OpenID configuration - normally the <server>/auth/realms/<realm_name>
    discovery-url: http://10.32.0.198:8080/auth/realms/master
    # skip tls verify
    skip-openid-provider-tls-verify: true
    # the client id for the 'client' application
    client-id: gatekeeper
    # the secret associated to the 'client' application
    client-secret: 23b73a87-92d9-4be6-b7b5-62b16d03b9d6
    # the interface definition you wish the proxy to listen, all interfaces is specified as ':<port>', unix sockets as unix://<REL_PATH>|</ABS PATH>
    listen: :3000
    # whether to enable refresh tokens
    enable-refresh-tokens: true
    # the location of a certificate you wish the proxy to use for TLS support
    tls-cert:
    # the location of a private key for TLS
    tls-private-key:
    # the redirection url, essentially the site url, note: /oauth/callback is added at the end
    redirection-url:  http://192.168.64.10.xip.io:8090
    secure-cookie: false
    # the encryption key used to encode the session state
    encryption-key: vGcLt8ZUdPX5fXhtLZaPHZkGWHZrT6aa
    # the upstream endpoint which we should proxy request
    upstream-url: http://127.0.0.1:80/
    forbidden-page: /html/access-forbidden.html
    resources:
    - uri: /*
      groups:
      - myapp
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: gatekeeper-files
  namespace: ns-keycloak

data:
  access-forbidden.html: |+
        <html lang="en"><head> <title>Access Forbidden</title><style>*{font-family: "Courier", "Courier New", "sans-serif"; margin:0; padding: 0;}body{background: #233142;}.whistle{width: 20%; fill: #f95959; margin: 100px 40%; text-align: left; transform: translate(-50%, -50%); transform: rotate(0); transform-origin: 80% 30%; animation: wiggle .2s infinite;}@keyframes wiggle{0%{transform: rotate(3deg);}50%{transform: rotate(0deg);}100%{transform: rotate(3deg);}}h1{margin-top: -100px; margin-bottom: 20px; color: #facf5a; text-align: center; font-size: 90px; font-weight: 800;}h2, a{color: #455d7a; text-align: center; font-size: 30px; text-transform: uppercase;}</style> </head><body> <use> <svg version="1.1" xmlns="http://www.w3.org/2000/svg" xmlns:xlink="http://www.w3.org/1999/xlink" x="0px" y="0px" viewBox="0 0 1000 1000" enable-background="new 0 0 1000 1000" xml:space="preserve" class="whistle"><g><g transform="translate(0.000000,511.000000) scale(0.100000,-0.100000)"><path d="M4295.8,3963.2c-113-57.4-122.5-107.2-116.8-622.3l5.7-461.4l63.2-55.5c72.8-65.1,178.1-74.7,250.8-24.9c86.2,61.3,97.6,128.3,97.6,584c0,474.8-11.5,526.5-124.5,580.1C4393.4,4001.5,4372.4,4001.5,4295.8,3963.2z"/><path d="M3053.1,3134.2c-68.9-42.1-111-143.6-93.8-216.4c7.7-26.8,216.4-250.8,476.8-509.3c417.4-417.4,469.1-463.4,526.5-463.4c128.3,0,212.5,88.1,212.5,224c0,67-26.8,97.6-434.6,509.3c-241.2,241.2-459.5,449.9-488.2,465.3C3181.4,3180.1,3124,3178.2,3053.1,3134.2z"/><path d="M2653,1529.7C1644,1445.4,765.1,850,345.8-32.7C62.4-628.2,22.2-1317.4,234.8-1960.8C451.1-2621.3,947-3186.2,1584.6-3500.2c1018.6-501.6,2228.7-296.8,3040.5,515.1c317.8,317.8,561,723.7,670.1,1120.1c101.5,369.5,158.9,455.7,360,553.3c114.9,57.4,170.4,65.1,1487.7,229.8c752.5,93.8,1392,181.9,1420.7,193.4C8628.7-857.9,9900,1250.1,9900,1328.6c0,84.3-67,172.3-147.4,195.3c-51.7,15.3-790.8,19.1-2558,15.3l-2487.2-5.7l-55.5-63.2l-55.5-61.3v-344.6V719.8h-411.7h-411.7v325.5c0,509.3,11.5,499.7-616.5,494C2921,1537.3,2695.1,1533.5,2653,1529.7z"/></g></g></svg></use><h1>403</h1><h2>Not this time, access forbidden!</h2><h2><a href="/oauth/logout?redirect=https://google.com">Logout</h2></body></html>
---

After successfully applying the yamls you should see sample web app pod running with service deployed.


kubectl get all -n ns-keycloak

NAME                                READY   STATUS    RESTARTS   AGE
pod/nginx-gatsby-5465669d87-dpd4k   2/2     Running   0          39m

NAME                   TYPE       CLUSTER-IP   EXTERNAL-IP   PORT(S)        AGE
service/nginx-gatsby   NodePort   10.32.0.53   <none>        80:30974/TCP   100m

NAME                           READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/nginx-gatsby   1/1     1            1           39m

NAME                                      DESIRED   CURRENT   READY   AGE
replicaset.apps/nginx-gatsby-5465669d87   1         1         1       39m

Ensure the two port-forwards are running and now you could hit the gatekeeper sidecar url.

Now, I am going show you “Access denied” to the application. To show this, I will use “tuser3” which does not belong to group “myapp”.

After you login you will not be able to access the sample web application that is hosted along with the gatekeeper container

404 404

Now try login using the user credentials “tuser1”, who belong to the group “myapp”. You will be sucessfully authenticated and the sidecar would redirect the url to the actual application.

Application app

Here is the view of the gatekeeper container logs

Gatekeeper-logs k9s Conclusion:

This shows how you can leverage the Identity and access management tools to authenticate applications without having to write single line of code in the web application. This leverages the kubernetes distributed design of containers and pods. Additionaly if you are looking for consealing the applications further you can look at enforcing pod newtork polices as well as look at leveraging service mesh technology to enforce more security controls.
